Fanvil X5U IP Phone

Fanvil X5U IP Phone Specification

Material
Plastic

Use
Office

Screen
Yes

Caller ID
Yes

DND Feature
Yes

Color
Black

Interface
Yes

Fanvil X5U IP Phone Trade Information

Minimum Order Quantity
2 Pieces

Payment Terms
Cash on Delivery (COD)

Sample Available
Yes

Packaging Details
Desktop stand (angles 1: 45 degree): 214x188.6x181.1 mm Desktop stand (angles 2: 50 degree): 214x180.5x190.1 mm Wall-mounted: 214x119.4x219.1 mm Gift box dimensions: 315x228x84 mm Outer CTN dimensions: 476x440x335 mm (10 PCS)

About Fanvil X5U IP Phone

X5U Enterprise IP Phone Generic 16 SIP Lines HD voice PoE enabled 2 LCDs Main DSS Intelligent DSS keys Handset handsfree headset mode Desktop stand wallmounted need an additional wall hanging parts Optional external power supply Phone Functions Local phonebook 2000 entries Remote phonebook XMLLDAP 2000 entries Call logs inoutmissed 1000 entries BlockedAllowed List Screen saver Voice message waiting indication VMWI Programmable DSSsoft keys Network time synchronization Builtin Bluetooth42 support Bluetooth headset Bluetooth of mobile device Support WiFi Dongle Via WF20 Support Poly wireless headset through Poly APD80 EHS cable Support Jabra wireless headset through Fanvil EHS20 EHS cable Support recording through flash drive or server Action URL Active URI uaCSTA Call Functions Call out answer reject Mute unmute microphone Call hold resume Call waiting Intercom Caller ID display Speed dial Anonymous call hide caller ID Call forward AlwaysBusyNo Answer Call transfer AttendedUnattended Call parkingpickup depending on server Redial DoNotDisturb Autoanswering Voice message with server 6way audio conference Hot line Hot desking X5U is an enterprise IP Phone featuring 35inch main color screen and 24inch extended screen HD voice gigabit Ethernet 16 SIP lines PoE Builtin Bluetooth 6way audio conference and other extended features like EHS headset It provides the highquality and convenient experience for users Highlights 35inch main color screen and 24inch extended screen for DSS keys HD audio on speakerphone and handset Support 6way audio conference 4 Line keys on the main display 6 DSS keys on the extended screen up to 30 DSS keys via 5 pages Builtin Bluetooth 42 support Bluetooth headset support WiFi Dongle Support EHS wireless headset Dual Gigabit ports integrated PoE Stand with 2 adjustable angles of 45 and 50 degrees

udio Deployment Management HD voice microphonespeaker handsethandsfree 0 7KHz frequency response HAC handset Wideband ADCDAC 16KHz sampling Narrowband codec G711au G729AB iLBC G7231 G726 Wideband codec G722 Opus Fullduplex Acoustic Echo Canceller AEC Voice Activity Detection VAD Comfort Noise Generation CNG Background Noise Estimation BNE Noise Reduction NR Automatic Gain Control AGC Packet Loss Concealment PLC Dynamic adaptive jitter buffer DTMF Inband OutofBand RFC2833 SIP INFO VQM voice quality monitoring Network Physical 101001000Mbps ethernet dual bridged port for PC bypass IP ModeIPv4IPv6IPv4IPv6 IP Configuration Static IP DHCP PPPoE Network Access Control 8021x VPN L2TP OpenVPN VLAN LLDP CDP QoS RTCPXR RFC3611 VQRTCPXR RFC6035 Protocols SIP20 over UDPTCPTLS RTPRTCPSRTP STUN DHCP IPv6 LLDP CDP PPPoE 8021x L2TP OpenVPN SNTP FTPTFTP HTTPHTTPS TR069 AES128 AES256 Autoprovisioning via FTPTFTPHTTPHTTPSDHCP OPT66SIP PNPTR069 Web management portal Webbased packet dump Configuration export import Phonebook importexport Firmware upgrade Syslog Physical Specifications Main LCD 35inch 480x320 color screen DSS keymapping LCD 24inch 240x320 color screen Keypad 42 keys including 4 Line keys with LED indicator light 4 Softkeys 6 Function keys Hold Call forward Conference MWI Headset Redial 4 Navigation keys 1 OK key 12 Standard phone digits keys 3 Volume control keys UpDownMute Microphone 6 DSS keys with LED indicator light 1 Pageswitch PS key with LED indicator light 1 Handsfree key with LED indicator light HD handset RJ9 x1 Standard RJ9 handset cord x1 15M CAT5E ethernet cable x1 Back rack x1 Status indicator light x1 Red RJ9 port x2 handset x1 headset x1 RJ45 port x2 network x1 PC x1 bridged to network USB20 port x1 Standard A connect with flash driver DC port x1 55x21x10mm Safety keyhole x1 DC power input DC5V 2A Power consumptionstandby091Whigh474W Power supply Power consumptionstandby13Whigh681W POE Working temperature 045 Working humidity 1095 Installation Desktop stand Wallmounted need an additional wall hanging parts Color black NWCTN 1185 kg GWCTN 1266 kg Device dimensions Desktop stand angles 1 45 degree 214x1886x1811 mm Desktop stand angles 2 50 degree 214x1805x1901 mm Wallmounted 214x1194x2191 mm Gift box dimensions 315x228x84 mm Outer CTN dimensions 476x440x335 mm 10 PCS

FAQs of Fanvil X5U IP Phone:

Q: How does the DND (Do Not Disturb) feature work on the Fanvil X5U IP Phone?

A: The DND feature on the Fanvil X5U IP Phone silences incoming calls, ensuring you are not disturbed. You can activate it directly from the phones menu or via a dedicated button, depending on your configuration.

Q: What is the benefit of the Caller ID feature on the Fanvil X5U IP Phone?

A: The Caller ID feature allows you to see the name or number of the incoming caller on the phones screen, making it convenient to identify callers before answering.

Q: What type of display does the Fanvil X5U IP Phone have?

A: The Fanvil X5U comes with a screen that provides clear visuals for navigation and caller information, enhancing user experience.

Q: Where can the Fanvil X5U IP Phone be most effectively used?

A: The Fanvil X5U is best suited for office environments, where its features, such as a professional design, advanced caller ID, and DND functionality, meet day-to-day communication needs.
